OMRON EE-SPX613 Dimensions
/Images/l_287-25-118803-198x198.jpglast update: December 19, 2013
• Operation mode selector allows modes to be switched easily.
• Sensitivity selector is suitable for any 6- to 13-mm-diameter transparent or semi-transparent pipe with a wall thickness of 1 mm.
• Uses a clean (with no powder parting agent) cable.
• Operating voltage range: 12 to 24 VDC
last update: December 19, 2013
Purchase the OMRON For Special Applications Please fill in the following
If you have just landed here, this product OMRON EE-SPX613 Sensors,Sensors is offered online by Tianin FLD Technical Co.,Ltd. This is an online store providing Sensors at wholesale prices for consumers. You can call us or send enquiry, we would give you the prices, packing,deliverty and more detailed information on the EE-SPX613 We cooperate with DHL,TNT,FEDEX,UPS,EMS,etc.They guarantee to meet your needs in terms of time and money,even if you need your OMRON EE-SPX613Sensors tomorrow morning (aka overnight or next day air) on your desk, 2, 3 days or more.Note to international customers, YES, we ship worldwide.
E8Y Differential Pressure Sensor/Features
D4B-[]N Safety Limit Switch/Features
A3S (Super Luminosity Type) Lighted Pushbutton Switch (Square) Ultra Bright LED Type/Features
D4NS, D4NS-SK Safety-door Switch/Features
E5L Electronic Thermostat/Features
OMRON EE-SPX613 lineup
EE-SPX613 Pipe-mounting Liquid Level Photomicrosensor with Built-in Amplifier/Lineuplast update: September 24, 2012
| Appearance | Sensing method | Output type | Output configuration | Cable length | Model |
|---|---|---|---|---|---|
 | Through-beam type | NPN output | Dark-ON or Light-ON (selectable) | 1 m | EE-SPX613 1M |
last update: September 24, 2012
OMRON EE-SPX613 dimension
EE-SPX613 Pipe-mounting Liquid Level Photomicrosensor with Built-in Amplifier/Dimensionslast update: September 24, 2012
Note:Tolerance class IT16 applies to dimensions in this datasheet unless otherwise specified.
EE-SPX613
last update: September 24, 2012
OMRON EE-SPX613 specification
EE-SPX613 Pipe-mounting Liquid Level Photomicrosensor with Built-in Amplifier/Specificationslast update: September 24, 2012
| Models | EE-SPX613 | |
|---|---|---|
| Applicable pipe | Any 6- to 13-mm-diameter pipe with a wall thickness of 1 mm that is made of FEP or any other material as transparent as FEP. | |
| Sensing object | Liquids in pipes (High-viscosity liquids or liquids with floating materials may not be detected.) | |
| Light source | GaAs infrared LED with a peak wavelength of 940 nm | |
| Indicator | Light indicator GaP (Red LED: Peak wavelength of 700 nm) | |
| Supply voltage | 12 to 24 VDC ±10%, ripple (p-p): 5% max. | |
| Current consumption | Average: 30 mA max., Peak: 80 mA max. | |
| Control output | NPN open collector: Load power supply voltage: 5 to 24 VDC Load current: 100 mA max. OFF current: 0.5 mA max. 100 mA load current with a residual voltage of 0.8 V max. 40 mA load current with a residual voltage of 0.4 V max. | |
| Ambient illumination | 3,000 lx max. with incandescent light or sunlight on the surface of the receiver | |
| Ambient temperature range | Operating: - 10 to +55 ° C Storage: - 25 to +65 ° C (with no icing or condensation) | |
| Ambient humidity range | Operating: 5% to 85% Storage: 5% to 95% (with no condensation) | |
| Vibration resistance | Destruction: 10 to 500 Hz, 1.0-mm single amplitude or 150 m/s2 in X, Y, and Z directions 3 times and for 11 min each | |
| Shock resistance | Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions | |
| Degree of protection | IEC 60529 IP50 | |
| Connecting method | Pre-wired (Standard length: 1 m) | |
| Weight (packed state) | Approx. 55 g | |
| Material | Case | Polycarbonate |
| Cover | ||
| Accessories | Support belt (2), slip protection tube (2), Instruction Manual | |
last update: September 24, 2012
OMRON EE-SPX613 catalog
EE-SPX613 Pipe-mounting Liquid Level Photomicrosensor with Built-in Amplifier/Catalog- Catalog
- Manual
- CAD
English
Global Edition
| Catalog Name | Catalog Number [size] | Last Update | |
|---|---|---|---|
 EE-SPX613 Data Sheet | - [325KB] | Aug 24, 201220120824 | EE-SPX613 Data Sheet |
